Īss

Funkcijas

• With a 12-ton capacity, it is designed to handle large volumes of waste. This makes it ideal for use in urban areas with high waste generation or in industrial settings.
• The electric power source provides a clean and sustainable alternative to traditional fuel-powered trucks. It reduces emissions and noise pollution, making it more environmentally friendly.

• The rear compactor is a key feature of this truck. It is designed to efficiently compress waste, maximizing the load capacity and reducing the number of trips required for waste disposal.
• The compaction system is powerful and reliable, capable of handling a wide variety of waste materials, including solid waste, recyclables, and bulky items.

• Equipped with advanced technology, the truck may have features such as intelligent control systems, real-time monitoring, and remote diagnostics. These can help optimize performance and ensure safe operation.
• Some models may also have features like automatic loading and unloading, which can further streamline waste management operations.

• Built with high-quality materials and components, the Yanlong 12 Ton Electric Rear Compactor Truck is designed to withstand the rigors of daily use. It has a sturdy chassis and a durable body that can resist corrosion and damage.
• Regular maintenance is made easy with accessible components and a user-friendly design. This helps to ensure long service life and minimal downtime.

• Safety is a top priority, and this truck is equipped with a range of safety features to protect operators and the public. These may include features such as anti-lock brakes, stability control, and backup cameras.
• The compactor mechanism is also designed with safety in mind, with features such as safety locks and emergency stop buttons.

• The truck can be used in a variety of waste management applications, including residential, commercial, and industrial waste collection. It can also be adapted to different waste types and disposal methods.
• Optional attachments and features can be added to customize the truck for specific needs, further enhancing its versatility.

Specifikācija

Pamatinformācija
Drive form	4X2
Garenbāze	4200mm
Body length	7.26 metri
Body width	2.42 metri
Body height	2.79 metri
Vehicle weight	7.88 tonnas
Rated load	3.825 tonnas
Total mass	11.9 tonnas
Maximum speed	88km/h
Factory standard range	320km
Motor
Motor type	Permanent magnet synchronous motor
Rated power	80KW
Peak power	160KW
Peak torque	1100N · m
Mounted equipment parameters
Vehicle type	Electric Rear Compactor Truck
Chassis parameters
Chassis series	Yanlong
Chassis model	LZ1121L3AZBEVT
Number of leaf springs	8/9+5
Front axle load	4300KG
Rear axle load	7600KG
Riepas
Tire specification	245/70R19.5
Number of tires	6 pieces
Akumulators
Battery type	Lithium iron phosphate battery
Battery capacity	214.645kvhs
Battery total voltage	531.3V
