SUMMARY
លក្ខណៈពិសេស
SPECIFICATIONS
ព័ត៌មានមូលដ្ឋាន | |
សំណុំបែបបទដ្រាយ | 4x2 |
រតង់កង់ | 4100មមលក់ម្យ៉ាង |
Vehicle length | 7.68 ម៉ែត្រ |
Vehicle width | 2.5 ម៉ែត្រ |
Vehicle height | 3.2 ម៉ែត្រ |
ទំងន់យានយន្ត | 6.28 តោន |
Rated load | 2.525 តោន |
ម៉ាស់សរុប | 9 តោន |
ល្បឿនអតិបរមា | 90គីឡូម៉ែត្រ / ម៉ោង |
CLTC cruising range | 400ខេម |
ប្រភេទប្រេងឥន្ធនៈ | hydrogen |
ម៉ាសីន | |
យីហោម៉ូតូ | ការត្រួតពិនិត្យបៃតង |
កមរុ | TZ370XS-LKM0757 |
ប្រភេទម៉ូទ័រ | permanent magnet synchronous drive motor |
ថាមពលកំពូល | 120KW |
អំណាចដែលបានវាយតម្លៃ | 60KW |
ប្រភេទប្រេង | hydrogen |
Cargo box parameters | |
Cargo box length | 4.27 ម៉ែត្រ |
Cargo box width | 2.24 ម៉ែត្រ |
Cargo box height | 2 ម៉ែត្រ |
Mounted equipment parameters | |
Other | Production enterprise: Xiongchuan Hydrogen Energy; Fuel cell form; Proton exchange membrane fuel cell; Peak power of fuel cell: 61KW; Hydrogen storage volume: 560ផោកធម; This vehicle is made by selecting the chassis with a wheelbase of 4100mm and equipping it with a refrigerated compartment and refrigeration equipment unit (different brands can be selected). High quality, high insulation, strong “hydrogen” quality, and environmentally friendly. The preferred model for cold chain transportation and distribution. Electronic control model: KTZ54X45S-LKC0757; Control mode: vector control; Electronic control cooling method:liquid cooling |
ប៉ារ៉ាម៉ែត្រតួ | |
Chassis series | Captur K7 |
Chassis model | EQ1090TACFCEVJ10 |
Number of leaf springs | 8/10+7 |
Front axle load | 3000ខេក |
Rear axle load | 6000ខេក |
សំបកកង់ | |
ការបញ្ជាក់សំបកកង់ | 9.5R17.5 14PR |
ចំនួនសំបកកង់ | 6 |
បាតឺរី | |
ម៉ាកថ្ម | តាល |
Battery model | L092B01 |
ប្រភេទថ្ម | lithium iron phosphate battery |
សមត្ថភាពថ្ម | 52.99គីឡូវ៉ាត់មុខ |
Energy density | 114.85Wh/kg |
Brand of electric control system | Suzhou Green Control |
